Digital Pupil Voltmeter, 20 V DC

Very easy to operate digital pupil voltmeter for measuring direct voltages. The device is housed in a sturdy ABS plastic case with non-slip feet and colour-coded 4 mm connectors.

It can be used for current student experiments around the topic of electricity. Instructions are included in the scope of delivery. The low operating current means the expected battery life is over 500 hours.

• accessories for our experiment set on electrical circuits
• easy to operate, ideal for teaching
• low power consumption, so long battery life

Technical details

• Measurement range: –20 to +20 V DC ±0.01 V
• Power supply: 9V block battery
• Display: 3½-digits, 13 mm high
• Input resistance: 100 M-Ohm
• Dimensions: 130 x 60 x 90 mm
• Mass: 180 g

Battery type: 9V block battery (1 x)

Please note:
Battery/electronic device disposal
